Set Filters and Custom Filter Logic in SvGrid
Build Excel-style checkbox set filters with live facet counts and a custom numeric range filter - using four API calls and plain Svelte markup.
Checkbox filters on a status column are more useful than a text input 90% of the time. If there are five possible values and 400 rows, nobody wants to type "delivered" - they want to click it, see the count drop to 98, and move on. SvGrid supports this through setFacetFilter and columnFilteringFeature, with live counts computed from api.getDisplayedRows() that reflect the currently filtered set, not the full dataset.
This post builds an order management grid with set filters on two columns (status and region), a numeric range filter on amount, and facet counts that update whenever any filter changes. I will call out the count-staleness problem, the empty-array trap in setFacetFilter, and why calling recomputeFacets() imperatively beats a reactive $effect for this use case.
Reproducible data first
Before wiring any filter logic, it is worth spending 30 seconds on data generation. Use a seeded PRNG instead of Math.random(). When you are chasing an edge case where two active filters together produce zero rows, reproducible data means you can share the exact scenario - not just a screenshot of the state you accidentally refreshed away.
// data.ts
export type Status = 'open' | 'paid' | 'shipped' | 'delivered' | 'returned'
export type Region = 'Americas' | 'EMEA' | 'APAC'
export type Order = {
id: string
customer: string
region: Region
status: Status
amount: number
}
const STATUSES: Status[] = ['open', 'paid', 'shipped', 'delivered', 'returned']
const REGIONS: Region[] = ['Americas', 'EMEA', 'APAC']
const NAMES = [
'Ava Thompson', 'Liam Park', 'Noah Singh', 'Emma Garcia',
'Olivia Chen', 'Mason Rivera', 'Sophia Brown', 'Lucas Patel',
]
let seed = 0x5EED01
function rand() { seed = (seed * 1664525 + 1013904223) >>> 0; return seed / 0xFFFFFFFF }
function pick<T>(arr: readonly T[]): T { return arr[Math.floor(rand() * arr.length)]! }
export const ORDERS: Order[] = Array.from({ length: 400 }, (_, i) => ({
id: `ORD-${40_000 + i}`,
customer: pick(NAMES),
region: pick(REGIONS),
status: pick(STATUSES),
amount: Math.round(50 + rand() * 4_950),
}))
// Derived from actual data - not hard-coded.
// If a new status appears (e.g. 'refunded'), the filter panel picks it up automatically.
export const ALL_STATUSES = [...new Set(ORDERS.map(o => o.status))] as Status[]
export const ALL_REGIONS = [...new Set(ORDERS.map(o => o.region))] as Region[]
Deriving the value lists from the dataset matters more than it looks. Hard-code ['open', 'paid', 'shipped', 'delivered', 'returned'] and the day your backend returns 'refunded', the filter panel silently ignores it. One line of Set construction eliminates that class of bug permanently.
Grid setup and filter state
columnFilteringFeature is the only feature registration needed on the grid side. The filter logic itself lives in three functions, each ending with an API call and a recomputeFacets() invocation.
<script lang="ts">
import {
SvGrid,
tableFeatures,
columnFilteringFeature,
rowSortingFeature,
type ColumnDef,
type SvGridApi,
} from '@svgrid/grid'
import { ORDERS, ALL_STATUSES, ALL_REGIONS, type Order } from './data'
const features = tableFeatures({ columnFilteringFeature, rowSortingFeature })
const columns: ColumnDef<Order>[] = [
{ accessorKey: 'id', header: 'Order ID', size: 110 },
{ accessorKey: 'customer', header: 'Customer', size: 160 },
{ accessorKey: 'region', header: 'Region', size: 100 },
{ accessorKey: 'status', header: 'Status', size: 110 },
{
accessorKey: 'amount',
header: 'Amount',
size: 100,
cell: ctx => `$${ctx.getValue<number>().toLocaleString()}`,
},
]
let api = $state<SvGridApi<Order> | null>(null)
// Local UI state for the filter panel
let selectedStatuses = $state<Set<string>>(new Set(ALL_STATUSES))
let selectedRegions = $state<Set<string>>(new Set(ALL_REGIONS))
let minAmount = $state(0)
let maxAmount = $state(5000)
// Per-value counts - recomputed after every filter change
let statusCounts = $state<Record<string, number>>({})
function recomputeFacets() {
if (!api) return
const counts: Record<string, number> = {}
for (const row of api.getDisplayedRows()) {
const s = row.status
counts[s] = (counts[s] ?? 0) + 1
}
statusCounts = counts
}
function onApiReady(ready: SvGridApi<Order>) {
api = ready
recomputeFacets()
}
function applyStatusFilter() {
if (!api) return
// Empty selectedStatuses means pass an empty array - see the trap section below
if (selectedStatuses.size === 0) {
api.clearFilter('status')
} else {
api.setFacetFilter('status', [...selectedStatuses])
}
recomputeFacets()
}
function applyRegionFilter() {
if (!api) return
if (selectedRegions.size === 0) {
api.clearFilter('region')
} else {
api.setFacetFilter('region', [...selectedRegions])
}
recomputeFacets()
}
function applyAmountFilter() {
if (!api) return
api.setFilter('amount', {
operator: 'between',
value: minAmount,
value2: maxAmount,
})
recomputeFacets()
}
function clearAll() {
if (!api) return
selectedStatuses = new Set(ALL_STATUSES)
selectedRegions = new Set(ALL_REGIONS)
minAmount = 0
maxAmount = 5000
api.clearAllFilters()
recomputeFacets()
}
</script>
The filter panel markup
No component library required. Each status label renders its live count from statusCounts. The region checkboxes are simpler - they do not show counts, but adding them is the same pattern.
<div class="filter-panel">
<section>
<h4>Status</h4>
{#each ALL_STATUSES as status}
<label>
<input
type="checkbox"
checked={selectedStatuses.has(status)}
onchange={() => {
if (selectedStatuses.has(status)) {
selectedStatuses.delete(status)
} else {
selectedStatuses.add(status)
}
selectedStatuses = new Set(selectedStatuses)
applyStatusFilter()
}}
/>
{status}
<span class="count">({statusCounts[status] ?? 0})</span>
</label>
{/each}
</section>
<section>
<h4>Region</h4>
{#each ALL_REGIONS as region}
<label>
<input
type="checkbox"
checked={selectedRegions.has(region)}
onchange={() => {
if (selectedRegions.has(region)) {
selectedRegions.delete(region)
} else {
selectedRegions.add(region)
}
selectedRegions = new Set(selectedRegions)
applyRegionFilter()
}}
/>
{region}
</label>
{/each}
</section>
<section>
<h4>Amount range</h4>
<input type="number" bind:value={minAmount} min={0} max={5000} />
<span>to</span>
<input type="number" bind:value={maxAmount} min={0} max={5000} />
<button onclick={applyAmountFilter}>Apply</button>
</section>
<button onclick={clearAll}>Clear all filters</button>
</div>
<SvGrid
{features}
{columns}
data={ORDERS}
{onApiReady}
style="height: 500px"
/>
Why facet counts must reflect the filtered view
There is a meaningful design decision here. Some filter panels show counts from the full dataset - "delivered (94)" regardless of any other active filter. That number is technically accurate but misleading once another filter is active. If the user has already narrowed to EMEA, "delivered (94)" implies they will see 94 rows when they check that box. They will not.
Computing counts from api.getDisplayedRows() means the numbers always reflect the intersection of all current filters. Check "EMEA" and the status counts drop to show only the EMEA breakdown. That is the right behavior - it matches how Excel's AutoFilter works and how users expect facets to work in any e-commerce search interface.
The tradeoff: counts can drop to zero. "open (0)" sounds odd, but it is honest - it tells the user the combination is empty rather than hiding the option. Hiding options when they would match zero rows is a different pattern entirely (and a harder one, because you need to evaluate hypothetical filter states rather than the current one).
Why recomputeFacets() is called explicitly, not in an $effect
The natural Svelte instinct would be to write something like:
$effect(() => {
if (api) {
statusCounts = computeCounts(api.getDisplayedRows())
}
})
The problem is timing. An $effect fires after Svelte's reactive updates settle. If you call api.setFacetFilter(...) and then an effect tries to read api.getDisplayedRows(), you are racing against SvGrid's internal filter pipeline. The pipeline may not have re-evaluated yet, so you get the counts from the previous filter state.
Calling recomputeFacets() immediately after the API call sidesteps this entirely. The API call is synchronous - by the time it returns, SvGrid has already re-evaluated the filter and updated the displayed row set. Reading getDisplayedRows() right after is guaranteed to reflect the new state.
The empty-array trap in setFacetFilter
api.setFacetFilter('status', []) does not clear the filter. It installs a filter that matches nothing - zero rows pass it. This is almost never what you want when the user unchecks every checkbox.
The correct behavior when all options are deselected depends on your app's semantics. In the example above, I treat it as "no filter applied" and call api.clearFilter('status') instead. If your intent is "show nothing when no options are selected," then passing an empty array is correct. The distinction matters - pick the one that matches your expected UX and handle the empty case explicitly.
Two active column filters
setFacetFilter is scoped to a single column ID. Calling it on 'status' does not affect the filter on 'region'. You can verify this with api.getFilters() after applying both - it returns separate entries keyed by column ID. The amount range filter using api.setFilter coexists with both set filters without any conflict. SvGrid evaluates all active column filters together: every displayed row satisfies all of them simultaneously.
Clearing selectively is equally scoped. api.clearFilter('status') removes only the status filter. api.clearAllFilters() removes everything - that is what the "Clear all" button uses, since it also resets the amount range and both checkbox selections.
The total SvGrid surface area in this implementation is four API methods: setFacetFilter, setFilter, clearFilter, clearAllFilters, and one read: getDisplayedRows. Everything else - the checkbox markup, the count display, the local state - is plain Svelte.
