Reducing Re-Renders in SvGrid with $derived

Svelte 5's $derived memoizes your row pipeline so the grid recomputes only when filter inputs actually change - not on every unrelated state update.

Most performance bugs in data grid pages are not inside the grid. They are in the code that feeds the grid. Specifically: expensive row transformations that run on every reactive tick, including ticks triggered by UI state that has nothing to do with the data.

Reducing Re-Renders in SvGrid with $derived

Svelte 5's $derived fixes this at the language level. When you wrap your filter and sort logic in $derived, Svelte tracks which $state signals the expression actually reads and only re-evaluates when one of those signals changes. Toggle a sidebar, switch a theme, update a tab - none of those touch your row pipeline.

Here is what that buys you on a 5,000-row grid: instead of re-filtering on every reactive update, the filter runs only when the user changes a search term or a filter control. For a typical Array.prototype.filter pass over 5,000 objects, that is the difference between running every 16ms and running a handful of times per second at most.

Why an inline expression is not enough

The most common anti-pattern is computing filtered rows inline in the template or inside a $effect:

<script lang="ts">
  let rows = $state<Deal[]>(seedDeals(5_000))
  let query = $state('')
  let sidebarOpen = $state(false) // unrelated UI

  // This recomputes on EVERY reactive update, including sidebarOpen changes.
  // $effect is the wrong tool here.
  let visibleRows = $state<Deal[]>([])
  $effect(() => {
    visibleRows = rows.filter(r => r.customer.toLowerCase().includes(query.toLowerCase()))
  })
</script>

<!-- Same problem if you filter inline - Svelte re-evaluates the whole block -->
<SvGrid data={rows.filter(r => r.customer.includes(query))} {columns} />

The $effect version adds an extra reactive cycle and is easy to get out of order. The inline version recalculates every time anything in the component re-renders. Both couple your row computation to the entire reactive graph of the page.

$derived breaks that coupling by being explicit about dependencies.

Building a memoized row pipeline

A real deal-pipeline view has multiple filter stages: active/inactive toggle, region dropdown, text search. Each should be its own $derived so invalidation is as narrow as possible. If only the search text changes, the active/inactive and region derivations return their cached values immediately.

<script lang="ts">
  import SvGrid from '@svgrid/grid'
  import {
    tableFeatures,
    rowSortingFeature,
    columnFilteringFeature,
    rowSelectionFeature,
    type ColumnDef,
    type SvGridApi,
  } from '@svgrid/grid'

  type Stage = 'discovery' | 'qualified' | 'proposal' | 'negotiation' | 'closed_won' | 'closed_lost'
  type Region = 'NA' | 'EMEA' | 'APAC' | 'LATAM'

  type Deal = {
    id: string
    customer: string
    region: Region
    stage: Stage
    amount: number
    active: boolean
  }

  const features = tableFeatures({
    rowSortingFeature,
    columnFilteringFeature,
    rowSelectionFeature,
  })

  // Source data - loaded once, updated surgically via applyTransaction
  let rows = $state<Deal[]>(seedDeals(5_000))

  // Filter controls - these are the only things that should trigger row recomputes
  let query = $state('')
  let regionFilter = $state<Region | 'ALL'>('ALL')
  let showInactive = $state(false)

  // Unrelated UI - must not touch the data pipeline
  let sidebarOpen = $state(false)
  let activeTab = $state<'pipeline' | 'forecast'>('pipeline')

  // Stage 1: active flag filter - invalidates only when showInactive or rows changes
  let activeRows = $derived(
    showInactive ? rows : rows.filter(r => r.active)
  )

  // Stage 2: region filter - only reruns when regionFilter or activeRows changes
  let regionRows = $derived(
    regionFilter === 'ALL'
      ? activeRows
      : activeRows.filter(r => r.region === regionFilter)
  )

  // Stage 3: text search - reruns when query or regionRows changes
  let visibleRows = $derived(
    query.trim() === ''
      ? regionRows
      : (() => {
          const q = query.toLowerCase()
          return regionRows.filter(r => r.customer.toLowerCase().includes(q))
        })()
  )

  // Stage 4: sort + aggregate in one pass using $derived.by for multi-step logic
  const pipeline = $derived.by(() => {
    const sorted = visibleRows.slice().sort((a, b) => b.amount - a.amount)
    let total = 0
    for (const d of sorted) total += d.amount
    const avg = sorted.length ? Math.round(total / sorted.length) : 0
    return { rows: sorted, count: sorted.length, total, avg }
  })

  const columns: ColumnDef<typeof features, Deal>[] = [
    { id: 'id',       field: 'id',       header: 'ID',       width: 80  },
    { id: 'customer', field: 'customer', header: 'Customer',  width: 220 },
    { id: 'region',   field: 'region',   header: 'Region',    width: 100 },
    { id: 'stage',    field: 'stage',    header: 'Stage',     width: 140 },
    {
      id: 'amount',
      field: 'amount',
      header: 'Amount',
      width: 130,
      type: 'number',
      format: { type: 'currency', currency: 'USD', options: { maximumFractionDigits: 0 } },
    },
  ]

  let api = $state<SvGridApi<typeof features, Deal> | null>(null)

  function seedDeals(n: number): Deal[] {
    const stages: Stage[] = ['discovery', 'qualified', 'proposal', 'negotiation', 'closed_won', 'closed_lost']
    const regions: Region[] = ['NA', 'EMEA', 'APAC', 'LATAM']
    return Array.from({ length: n }, (_, i) => ({
      id: `D-${String(i + 1).padStart(5, '0')}`,
      customer: `Customer ${i + 1}`,
      region: regions[i % regions.length]!,
      stage: stages[i % stages.length]!,
      amount: 10_000 + (i * 37) % 490_000,
      active: i % 7 !== 0,
    }))
  }

  const fmt = new Intl.NumberFormat('en-US', { style: 'currency', currency: 'USD', maximumFractionDigits: 0 })
</script>

<div class="toolbar">
  <input bind:value={query} placeholder="Search customer..." />
  <select bind:value={regionFilter}>
    <option value="ALL">All regions</option>
    <option value="NA">NA</option>
    <option value="EMEA">EMEA</option>
    <option value="APAC">APAC</option>
    <option value="LATAM">LATAM</option>
  </select>
  <label>
    <input type="checkbox" bind:checked={showInactive} />
    Show inactive
  </label>
  <button onclick={() => (sidebarOpen = !sidebarOpen)}>Toggle sidebar</button>
</div>

<p class="summary">
  {pipeline.count} rows - {fmt.format(pipeline.total)} total - {fmt.format(pipeline.avg)} avg
</p>

<SvGrid
  data={pipeline.rows}
  {columns}
  {features}
  rowId="id"
  height={560}
  onApiReady={(g) => (api = g)}
/>

sidebarOpen and activeTab are never read by any $derived expression. Toggling the sidebar triggers zero work in the row pipeline. The summary stats recalculate only when pipeline.rows recalculates, not independently.

How the dependency tracking works in practice

Svelte 5's reactivity is a directed acyclic graph of signals. When $derived(expr) runs for the first time, the runtime records every $state signal read during evaluation. That recorded set is the exact dependency list - nothing more.

The chain rows -> activeRows -> regionRows -> visibleRows -> pipeline means each node only propagates invalidation as far down as the first input that actually changed. Change query: rows, activeRows, and regionRows are clean, so Svelte skips them and re-evaluates only visibleRows and pipeline. Change regionFilter: activeRows is clean, only regionRows, visibleRows, and pipeline rerun.

This is different from Svelte 4 reactive statements ($:) where evaluation order is determined at compile time and the granularity is the statement, not the signal. In Svelte 5, each $derived is independently memoized with its own dependency set.

When memoization breaks down

Two common mistakes negate the benefit.

The first is replacing the source array on every tick with a brand-new reference:

// Polling loop that assigns a new array even when the data hasn't changed
$effect(() => {
  const interval = setInterval(async () => {
    rows = await fetchDeals() // new reference even if content is identical
  }, 5_000)
  return () => clearInterval(interval)
})

Every assignment to rows - regardless of content - invalidates every downstream $derived. If you need live updates, diff the incoming payload and apply changes surgically:

$effect(() => {
  const interval = setInterval(async () => {
    const fresh = await fetchDeals()
    if (!api) return

    const current = new Map(api.getData().map(r => [r.id, r]))
    const incoming = new Map(fresh.map(r => [r.id, r]))

    const add = fresh.filter(r => !current.has(r.id))
    const remove = api.getData().filter(r => !incoming.has(r.id))
    const update = fresh.filter(r => {
      const old = current.get(r.id)
      return old && JSON.stringify(old) !== JSON.stringify(r)
    })

    api.applyTransaction({ add, update, remove })
  }, 5_000)
  return () => clearInterval(interval)
})

applyTransaction patches the grid's internal row model incrementally. The rows signal does not change, so activeRows, regionRows, and the rest of the chain are untouched.

The second mistake is chaining too many derivations over a large dataset. Four passes of Array.prototype.filter over 5,000 rows, each taking 1-2ms, is 4-8ms of synchronous work on the reactive thread. If you measure that as a problem, collapse the chain into a single $derived.by that does all filtering in one loop:

const visibleRows = $derived.by(() => {
  const q = query.toLowerCase().trim()
  const result: Deal[] = []
  for (const r of rows) {
    if (!showInactive && !r.active) continue
    if (regionFilter !== 'ALL' && r.region !== regionFilter) continue
    if (q && !r.customer.toLowerCase().includes(q)) continue
    result.push(r)
  }
  return result
})

One pass, three conditions, one dependency set that covers rows, showInactive, regionFilter, and query together. This is worth doing only if profiling confirms the multi-stage version is actually slow - the chained approach is easier to read and test.

Interaction with grid features

One boundary to be aware of: $derived and SvGrid's built-in sort/filter features work on different layers. If you pass pre-sorted data via $derived and also enable the rowSortingFeature in tableFeatures, the grid sorts an already-sorted array. The user sees correct order, but the two systems fight over the result when column headers are clicked.

The cleaner split: use $derived for transformations the grid's built-in features cannot express (custom business rules, cross-row aggregation, async enrichment results written to $state). Use grid features for standard column sorting and filter rows that the user controls interactively through the header UI. Mixing both for the same transformation creates maintenance confusion.

For server-side data via createServerDataSource, the question becomes moot - filtering and sorting happen on the server and the client-side derivation chain only ever sees one page of results at a time. That is the correct architecture for datasets above roughly 50,000 rows.

Tagged: Performance, Svelte runes, Reactivity
